Tuesday, 27 February 2018

Promax PL218A Speaker


The Promax PL218A is a very powerful Sub-bass Active Line Array system serial, it hase been designed to be couple with PL212A & PL112A Line Array system to extend and increase the total low frequency output. It also can be used as very powerful low frequency with built in Class D 4000W amplifier DSP processing. The Promax PL218A provide a good low-bass punch with extend sub-bass output from two direct radiating 18"(450mm) Neodymium driver working 5"(125m) high temperature voice coil

FEATURES


  • 141 dB Peak SPL
  •  Dual 18" Neodymium Dual Voice Coil low-frequency driver for low-distortion and higher SPL
  • Multiple injection molded handles with backing cup for easy transport
  • Lightweight poplar plywood cabinets made structurally sound with tongue and groove joints
  • Cloth backed, dent-resistant 16 gauge steel grilles
  • Rated power                                 2000w AES, 4000w Peak
  • Number of Input driver                 2xNL4FC speakon
  • Heightx WidthxDepth                    620x1278x731mm
  • Weight                                           55 kg
  • Voltage operation                          220V/50-60HZ


























































































































































Tuesday, 3 May 2016

Promax PF15+ Speaker


The Promax PF15+ is a high-power serial, lightweight two-way loudspeaker system capable of delivering a very high level of performance over a broad bandwidth. Compact 2 way system with a 15"(380) Neodymium dual voice coil LF driver and a 1.7" (38mm) exit neodymium compression driver mounted  a rotatable 80°×50° constant directivity HF horn. It is the ideal choice for full-range applications calling for an efficient, reliable workhorse that is equally suitable for fixed installations and quick deployment mobile operations.
FEATURES


  • 137 dB Peak SPL
  •  Dual 15" Dual Voice Coil low-frequency driver for low-distortion and higher SPL
  • 1.75" diameter Promax neodymium compression driver
  • Multiple injection molded handles with backing cup for easy transport
  • Lightweight poplar plywood cabinets made structurally sound with tongue and groove joints
  • Cloth backed, dent-resistant 14 gauge steel grilles
  • Rated power                                  600w AES, 1200w Peak
  • Number of Input driver                   2xNL4FC speakon
  • Dimensions:HxWxD                      690x440x420mm
  • Weight                                             28 kg



















































































































































































Monday, 2 May 2016

ProMax P12A Active Speaker


ProMax P12A is active fullrange system speaker, 2-ways system, designed to provide exceptional club sound reinforcement and stage monitoring from a very compact enclosure. It features a powerful 12″(305mm) low frequency driver and a 1.5″(37mm) HF compression driver mounted on a constant directivity 90°×50° horn. Depending on the application, the HF horn can be rotated to allow the multi-angle enclosure to be used in either its vertical or horizontal orientation.

FEATURES


  • 134 dB Peak SPL
  • 12" Dual Voice Coil low-frequency driver for low-distortion and higher SPL
  • 1.5" diameter Promax compression driver
  • Multiple injection molded handles with backing cup for easy transport
  • Lightweight poplar plywood cabinets made structurally sound with tongue and groove joints
  • Cloth backed, dent-resistant 14 gauge steel grilles
  • Rated power                                  400w AES, 800w Peak
  • Number of Input driver                   2xNL4FC speakon
  • Dimensions:HxWxD                      582x394x340mm
  • Weight                                             22 kg
  • Voltage operation                           220V/50-60HZ













































































































































Tuesday, 5 April 2016

Promax PL112A Active Line Array Speaker


The Promax PL112A is a high-power Active Line Array system serial, lightweight two-way loudspeaker system capable of delivering a very high level of performance over a broad bandwidth. Compact 2 way system with 1x12"(380) Neodymium dual voice coil LF driver and 2x1.7" (38mm) exit neodymium compression driver mounted  a rotatable 80°×50° constant directivity HF horn. It is the ideal choice for tours applications, Theater, disco bar...


FEATURES


  • 138 dB Peak SPL
  •  Dual 1x12" Dual Voice Coil low-frequency driver for low-distortion and higher SPL
  • Dual 2x1.75" diameter Promax neodymium compression driver
  • Multiple injection molded handles with backing cup for easy transport
  • Lightweight poplar plywood cabinets made structurally sound with tongue and groove joints
  • Cloth backed, dent-resistant 14 gauge steel grilles
  • Rated power                                  600w AES, 1200w Peak
  • Number of Input driver                   2xNL4FC speakon
  • Dimensions:HxWxD                      380x688x420mm
  • Weight                                             29 kg
  • Voltage operation:                          220V/50-60HZ
